Alphacool ES PWM fan - 120mm

Alphacool ES PWM fan - 120mm

120mm fan for servers / workstations / radiators, max. 4,000 RPM, 4-pin PWM connector, durable double ball bearing
22,90 €
incl. VAT , add. delivery costs starting from 4.99€
SKU LUAC-037 |
EAN 4250197248174 |
MPN 24817 |
Manufacturer Alphacool
  • High-performance 120mm fan for servers and workstations
  • Extremely high speed of up to 4,000 RPM for efficient cooling performance
  • Dynamic fan speed thanks to PWM technology
  • Completely silent in idle mode
  • Durable double ball bearing
  • Offers multiple protection circuits to safeguard the fan and your system

Efficient cooling performance for servers

The Alphacool ES PWM fan delivers top-tier cooling performance thanks to its speed of up to 4,000 RPM. The case fan generates an extreme static pressure of 12.67mmH2O and a flow rate of 203.88m³/h, effectively dissipating heat from the system or drawing in cold air to cool the components from outside. The fan is also excellent for use on your radiator.

Equipped with pulse width modulation, the fan only spins as fast as the current system performance demands. This ensures consistently quiet operation. In idle mode, the fan shuts down completely. The fan starts up very quietly, thereby increasing its lifespan and minimising the risk of injury. Under no circumstances should body parts come into contact with the fan blades at such high speeds.

The Alphacool ES PWM fan also features multiple protection circuits. For instance, the fan can be blocked for up to 72 hours without sustaining damage. Even in the event of accidental reverse polarity during connection, the electronics are protected from burning out for at least five seconds.

Colour
Primary Colour
Black
Secondary Colour
Black
Fan Main Colour (Frame)
Black
Fan Main Colour (Rotor)
Black
Dimensions
Length / Depth
120 mm
Width
120 mm
Fan height
25 mm
Fan Specifications
Fan Size
120 mm
Fan mounting size
120 mm
Fan Blade Direction
Regular
Min. Fan RPM
0 rpm
Max. Fan RPM
4000 rpm
Max. Single Fan Airflow
203.88 m³/h
Noise
Max. Single Fan Noise dB(A)
49.9 dB(A)
Internal Ports
Fan connectors
4 Pin (PWM)
Lighting
Lighting / RGB
No
Set
Set
No
