- 140mm PWM fan in black with frame
- 30mm thickness for more cooling efficiency
- Max 1,300 rpm and 32.9 dB(A)
- 147.64 m³/h max airflow and max 1.76 mmH2O static pressure
- 4-pin PWM and 3-pin ARGB connectors
- Rubber pads to decouple annoying vibrations
APNX FP1 140mm PWM ARGB Fan: Optimised Design Combined with High Performance
Are you looking for a fan that offers excellent cooling performance and makes your PC an eye-catcher? The APNX FP1 140mm PWM ARGB fan leaves nothing to be desired! Its efficiency-driven design moves more air into your case than conventional fans. At the same time, the fan remains particularly quiet even at high speeds.
APNX FP1 140mm PWM ARGB Fan: A Real All-Rounder
Disturbing fan noise is an absolute no-go for gamers. All the better that the APNX FP1 140mm PWM ARGB fans are naturally quiet thanks to their hydraulic bearings. The fan only generates a maximum of 32.9 dB(A) at a maximum of 1,300 rpm. Cool temperatures are also favoured by the increased height of 30 millimetres. The maximum values of 147.64 m³/h flow rate and 1.76 mmH2O static pressure speak for themselves.
Optimised Concept for Lighting and Design
APNX has also shown a fine hand in design. The most striking feature is the continuous frame of the APNX FP1, which not only gives the fans a unique look, but also fits seamlessly into the APNX ecosystem. The ARGB lighting is reduced to the rotor blades and the inside of the frame, giving your system a subtle look. Thanks to the 4-pin PWM and 3-pin ARGB sockets, the APNX FP1 140mm PWM ARGB fans can be connected to almost any standard equipped motherboard or controller.
Technical Details:
- Size: 140mm x 140mm x 30mm (W x H x D)
- Material: Plastic
- Colour: Black
- Bearing: Hydraulic
Speed: 500 - 1,300rpm
Noise level: 15.9 - 32.9dB(A)
Airflow: max 147.64m³/h
Static pressure: max 1.67mmH2O
Rated voltage: 12V
Rated starting voltage: 5V
Rated current: 0.4A
Power consumption: 4.8W - Connectors:
1x 4-pin PWM
1x 3-pin ARGB
Colour
|
|
Primary Colour
|
Black
|
Secondary Colour
|
White
|
Dimensions
|
|
Fan height
|
30 mm
|
Fan Specifications
|
|
Fan Size
|
140 mm
|
Fan mounting size
|
140 mm
|
Min. Fan RPM
|
500 rpm
|
Max. Fan RPM
|
1300 rpm
|
Max. Single Fan Airflow
|
147.64 m³/h
|
Power Specifications
|
|
Starting voltage
|
5 V
|
Noise
|
|
Min. Single Fan Noise dB(A)
|
15.9 dB(A)
|
Max. Single Fan Noise dB(A)
|
32.9 dB(A)
|
Internal Ports
|
|
Fan connectors
|
4 Pin (PWM)
|
RGB / LED connectors
|
1x Digital RGB (3-Pin 5VDG)
|
Lighting
|
|
Lighting / RGB
|
Yes
|
Lighting Colour
|
RGB
|
Set
|
|
Set
|
No
|
