Topseller!

ASRock
B450M Pro4, AMD B450 Mainboard - Sockel AM4

Review this product

Feature-rich B450 motherboard (Micro-ATX)
1x PCIe 3.0 x16 (x16) / 1x PCIe 2.0 x16 (x4) / 1x PCIe 2.0 x1
2x M.2 & 4x SATA 6G
2x USB 3.1 Type A & Type C / 6x USB 3.0 / 6x USB 2.0
max. 64 GB RAM up to 3.200 MHz
ELNA Audio Capacitors & 3x RGB-LED Header

from 17.12.19

89.90€*

Item number: MBAR-292

EAN: 4717677336276

MPN: 90-MXB8F0-A0UAYZ

Manufacturer: ASRock

Description
Videos (2)
Technical Details
Reviews (0)
Accessories (7)

Product information - B450M Pro4, AMD B450 Mainboard - Sockel AM4

The B450 chipset forms the centrepiece of the ASRock B450M Pro4 motherboard and has been specially developed and optimised for 2000- series (Pinnacle Ridge) Ryzen CPUs. B450 motherboards support all features of 2nd gen Ryzen processors, such as the AMD's new XFR2 overclocking. Additionally, the motherboards support up to 64 GB of RAM with a guaranteed clock frequency of 2.933 Megahertz. Overclocking to higher frequencies is also an option, although the increase will depend on the motherboard.

The Features of the ASRock B450M Pro4 at a Glance:

1x PCIe 3.0 x16 (x16) for high-end graphics cards
2x USB 3.1 (1x Type C, 1x Type A) / 6x USB 3.0 / 6x USB 2.0
1x M.2 (PCIe 3.0 x4) / 1x M.2 (SATA6G) / 4x SATA 6G
DDR4-RAM up to 3.200 MHz via OC
ELNA Audio Capacitors & digital RGB header

The Features of the ASRock B450M Pro4 in Detail:

The ASRock B450M Pro4 Micro-ATX motherboard offers a PCI-Express 3.0 slot with a full x16 lanes of connectivity for graphics cards as well as a PCI-Express 3.0 x16 slot with x4. The motherboard also provides a PCIe-x1 slot for additional expansion cards. The four RAM slots support up to 64 GB DDR4-RAM clocked at up to 2.933 MHz and this can even be increased up to 3.200 MHz via overclocking.

At the same time, two M.2 slots with PCIe connectivity are available thanks to the board being AM4-compatible. One of the slots is connected over four PCI-Express Lanes, while the other uses SATA6G speeds. M.2 SSDs that use the advanced NVM-Express protocol (NVMe) and that are connected with four PCI-Express 3.0 lanes are capable of speeds up to eight times faster than those of SATA 6G hard drives - supporting rates of up to 32 Gbit/s.

The ASRock B450M Pro4 on the I/O panel offers a USB 3.1 Type C connection as well as a USB 3.1 Type A connector. The USB Type C port can be inserted in either orientation and is particularly slim. USB 3.1 Gen 2 achieves speeds of up to 10 Gbit/s per port and USB ports using this standard support, as a rule, smartphones and tablets that offer fast charging. For CPUs with integrated graphics, such as AMD's Raven Ridge APUs, an HDMI-, a DVI-, and a D-Sub connector.

In terms of special features, the ASRock B450M Pro4 offers ELNA Audio Capacitors for clear onboard sound. Additionally the motherboard comes with two headers, one for static lighting and one header for addressable RGB elements. Needless to say, the board provides high-quality and robust power delivery for your CPU as well.

Technical Details:

Format:
Micro-ATX (244 x 244 mm)
Chipset:
AMD B450
Socket:
AM4 (for Pinnacle Ridge / Summit Ridge / Bristol Ridge / Raven Ridge)
RAM:
4x DDR4 (max. 2.933 MHz, 3.200 via OC)
Dual-Channel
max. 64 GB
Slots (with a Ryzen CPU):
1x PCIe 3.0 x16
1x PCIe 2.0 x16 (electrical x4)
Multi-GPU Configurations: 2-way AMD CrossFire
1x PCIe 2.0 x1
Internal Connections:
4x SATA 6G (RAID 0, 1, 10)
1x M.2 (M-Key, PCIe 3.0 x4 with max. 32 Gbit/s, Sizes 2242 to 2280)
1x M.2 (M-Key, SATA6G, sizes 2242 to 2280)
1x USB 3.0 Header (2 Ports)
2x USB 2.0 Header (4 Ports)
4x 4-Pin Fan (PWM)
1x 4-Pin Pump Connector
1x Front-Panel Audio Connector
1x COM Port Header
1x Chassis Intrusion Header
1x Power LED & Speaker Header
1x 3-Pin RGB-Header (5V)
2x 4-Pin RGB-Header (12V)
1x TPM Connector
External Connections:
2x USB 3.1 (1x Type A and Type C)
4x USB 3.0
2x USB 2.0
1x Gigabit LAN (Realtek RTL8111H)
1x DVI-D
1x HDMI
3x Audio (Realtek ALC892, 7.1 Sound)
Power Supply:
1x 24-Pin ATX12V
1x 8-Pin ATX12V

Further links for "B450M Pro4, AMD B450 Mainboard - Sockel AM4"

Videos

Technical Details

Motherboard form factor	Micro-ATX
CPU socket	AM4
Motherboard Chipset	AMD B450
Memory slots	4x
Memory type	DDR4
max. Memory	64 GB
PCIe (3.0) x16 (mechanical)	1x
PCIe (2.0) x4 (mechanical)	1x
PCIe (2.0) x1	1x
Fan connectors (4-Pin PWM)	5x
LED Anschlüsse	ja, RGB (4-Pin 5050 12VGRB) 2x, Digital RGB (3-Pin 5VDG)
SATA 6G internal	4x
M.2 (PCIe 3.0 x4)	1x
M.2 (SATA 6G)	1x
USB 3.1 external (Type A)	1x
USB 3.1 external (Type C)	1x
USB 3.0 internal	2x
Display connectors	DVI-D, HDMI
RJ-45 (LAN) Ports	1x (in total)
Wifi	no
Illumination	no
LED Kompatibilität	ASRock Polychrome Sync
