NZXT H9 Flow Mid Tower - Black
- Midi tower with four integrated 120 mm fans
- Side panel and front made of tempered glass
- Top, bottom, and rear side panel with ventilation holes
- Optimal cooling thanks to space for up to 9 fans and cold floor cooling
- 360 mm radiators possible at the back, on the top, or at the bottom
- Graphics cards up to a length of 435 mm possible
- Maximum CPU cooler height of 165 mm
Midi tower with tempered glass panorama and integrated fans
With the NZXT H9 Flow Midi Tower, you make no compromises when it comes to the aesthetics and cooling of your gaming PC. The side panel and front are made of tempered glass, allowing for an excellent all-round view of your installed components.
Good airflow despite front made of tempered glass
The NZXT H9 Flow offers good airflow for high-end hardware despite the continuous front panel made of tempered glass. There are ventilation holes at the bottom and on the right side panel, ensuring that enough cool fresh air flows in even with a closed front panel. Additionally, the case top is completely perforated, reliably expelling heated air from the case.
Furthermore, you have the option to install a total of nine 120 mm or four 140 mm fans in the H9 Flow, ensuring effective cooling throughout. The bottom accommodates three 120 mm or two 140 mm fans, the top also allows for three 120 mm or two 140 mm fans, and the rear has space for one 120 mm fan. Additionally, you can place three 120 mm fans next to the motherboard.
Many mounting options for radiators and water cooling
If you plan to equip your system with water cooling, the NZXT H9 Flow is an excellent choice. You can install a 360 mm radiator either next to the motherboard, at the bottom, or on the top. Additionally, you can also install a 120 mm radiator at the back if you want to use a small AiO water cooler for your CPU.
Ample space for your gaming hardware
The H9 Flow can accommodate two 3.5 or 2.5-inch drives. Additionally, there are four mounts for 2.5-inch drives.
Moreover, graphics cards up to a length of 435 mm and CPU coolers up to a height of 165 mm can be installed.
Well-equipped I/O panel
The I/O panel features a power button, HD audio and microphone jack, as well as one USB 3.1 Type-C port and two USB 3.0 Type-A ports for faster file transfer.
Technical details:
- Dimensions: 290 x 495 x 466 mm (W x H x D)
- Weight: 12.1 kg
- Colour: Black
- Material: Steel, tempered glass
- Form factor: Micro-ATX, Mini-ITX, ATX
- Total fans possible:
3x 120 mm or 2x 140 mm (bottom)
3x 120 mm or 2x 140 mm (top)
3x 120 mm (side)
1x 120 mm (rear) - Radiator mountings:
1x max. 360 mm (bottom)
1x max. 360 mm (top)
1x max. 360 mm (side)
1x max. 140 mm (rear) - Drive bays:
2x 3.5 inch or 2.5 inch
4x 2.5 inch - Power supply: 1x standard ATX (up to 200 mm)
- Expansion slots: 7
- I/O panel:
1x power button
2x USB 3.0 (Type-A, USB 3.2 Gen 1, max. 5 Gbit/s)
1x USB 3.1 (Type C, USB 3.2 Gen 2, max. 10 Gbit/s)
1x 3.5 mm combo jack - Maximum graphics card length: 435 mm
- Maximum CPU cooler height: 165 mm
- Included:
1x H9 Flow case
1x split front I/O cable
4x silent 120 mm airflow fans (case version)
1x installation accessories
1x manual
|
Colour
|
|
|
Primary Colour
|
Black Transparent (Matt/Frosted)
|
|
Secondary Colour
|
Black transparent (glossy)
|
|
Fan Main Colour (Frame)
|
Black
|
|
Dimensions
|
|
|
Length / Depth
|
466 mm
|
|
Width
|
290 mm
|
|
Height
|
495 mm
|
|
Weight
|
12.1 kg
|
|
Case
|
|
|
Case Type
|
Mid Tower
|
|
Motherboard Support
|
|
|
Compatible Motherboard Formats
|
ATX, Micro-ATX, Mini-ITX
|
|
Max. Motherboard Format
|
ATX
|
|
Internal Dimensions
|
|
|
Max. CPU Cooler Height
|
165 mm
|
|
Max. GPU Length
|
435 mm
|
|
Max. PSU Length / Depth
|
200 mm
|
|
Display
|
|
|
Display Included
|
No
|
|
Power Supply
|
|
|
PSU included
|
No
|
|
PSU Format
|
ATX
|
|
Power Supply Position
|
rear side
|
|
Fan Support
|
|
|
120 mm fans
|
10
|
|
140 mm fans
|
4
|
|
Radiator Support
|
|
|
Max. Radiator Compatibility
|
1x Single (140 mm), 3x Triple (360 mm)
|
|
Drive Bays
|
|
|
2.5 inch internal drive bay
|
6
|
|
3.5 inch internal drive bay
|
2
|
|
1x 3.5 / 1x 2.5 Inch Internal Drive Bays (combined)
|
2
|
|
Hot swap drive bays
|
No
|
|
External Ports
|
|
|
USB 3.2 (external) Type C
|
1
|
|
USB 3.1 (external) Type C
|
1
|
|
USB 3.0 (external) Type A
|
2
|
|
Audio outputs & inputs
|
1x output + 1x input (3.5 mm jack, 3-pin, TRS)
|
|
Card reader
|
No
|
|
Case Features
|
|
|
I/O position
|
Front
|
|
Side panel
|
closed
|
|
Front door
|
Yes
|
|
Cable Management
|
Yes
|
|
Filters Included
|
Yes
|
|
Noise dampening
|
No
|
|
Mainboard slide / tray
|
No
|
|
Remote included
|
No
|
|
Transport System
|
No
|
|
Expansion Slots
|
|
|
Expansion slots / PCI slots
|
7
|
|
Features
|
|
|
Housing Feedthrough
|
No
|
|
Materials
|
|
|
Materials
|
Steel, Tempered Glass
|
|
Lighting
|
|
|
Lighting / RGB
|
No
|
|
Fan / RGB control
|
Yes
|
|
Additional Contents
|
|
|
Included fans
|
None
|
