SAPPHIRE
Nitro+ Radeon RX 570 8G, 8192 MB GDDR5

  • Polaris Refresh: AMD Radeon RX 570 graphics card
  • 1.244/1.340 MHz Base-/Boost clock
  • Dual-X dual-fan cooler
  • RGB-LED lighting & backplate
  • 8 GB GDDR5 VRAM



archived



Item number: GCSP-167

EAN: 4895106282179

MPN: 11266-09-20G

Manufacturer: SAPPHIRE




Product information - Nitro+ Radeon RX 570 8G, 8192 MB GDDR5

The Sapphire Nitro+ Radeon RX 570 8G with semi-passive Dual X cooler reached a base clock of 1.244 MHz, boosting up to 1.340 MHz when required. The 8 GB GDDR5 VRAM is clocked at 3.500 MHz (7.000 MHz) and is conncted to the GPU via a 256-Bit memory interface. An 8-Pin power connector supplies the 26 cm long graphics card with the required power and a power supply capable of delivering 500 Watts is recommended.

In order to cool the graphics card effectively, Sapphire utilises a cooler with two fans and an additional backplate. LED lighting is also included. The special feature of this is the semi-passive dual-fan cooler with removable fans. Removing just one screw allows the fan to be removed for cleaning. In the rare instance of a problem with the fan it can then be sent in separately, without having to send in the whole graphics card.

The Features of the Sapphire Nitro+ Radeon RX 570 8G

  • Semi-passive Dual-X dual-fan cooler
  • RGB-LED lighting
  • GPU base clock: 1.244 MHz
  • Boost clock max. 1.340 MHz
  • 8 GB GDDR5 VRAM
  • Memory frequency: 3.500 MHz (effektiv 7.000 MHz)
  • 1× 8-Pin power connector

The AMD Radeon RX 570 (8 GB) in Detail

The Radeon RX 570 is AMD's premium HD gaming graphics card from the RX 500 graphics card series and is especially attractive for price-conscious gamers or owners of FreeSync monitors. The Polaris 20 graphics chip utilised in the RX 570 series is a "refresh" of the Polaris 10 architecture used in the RX 470 and offers the same number of shaders as its predecessor, 2.048 to be specific. Thanks to optimisations in the manufacturing process the Radeon RX 570 brings higher maximum boost clocks than its equivalents in the RX 400 series.

Based on AMD's fourth-gen GCN architecture and manufactured in the 14 nm FinFET-LPP process, the Radeon RX 570 also has a very low TDP of just 120 Watt. This has been made possible through huge technological leaps in control-, power saving and clock-rate technologies, and the contrast in power usage between this card and its preceding models such as the Radeon R9 390 (250 Watt TDP) makes for a noticeable improvement.

The 4th-gen Graphics Core Next architecture (GCN 1.3) introduces features such as a command processor, a geometry processor, new multimedia cores, an optimised display engine as well as an improved memory controller. Some of the supported technologies include Async Compute, Vulkan, DirectX 12 and AMD's FreeSync technology.

Monitors can be connected to the graphics card via DVI-D, Display-Port or HDMI. EyeFinity technology enables up to four monitors to be connected in a multi-display setup. The HDMI connector utilises HDMI 2.0b to allow playback of 4K/UHD resolution multimedia at 60 Hz and offers HDCP 2.2 for sending and receiving encrypted signals.

In order for the card to reach its maximum potential, new drivers should be downloaded and installed at regular intervals from the AMD or Sapphire websites.

Rapid Graphics Card Replacement at Caseking!

At Caseking, defective graphics cards of all the brands listed below that are validly returned (meaning that the faults can be verified by us) by customers during the two year warranty period, starting with the receipt of the goods, will be immediately replaced with a brand new card if in stock. This way, lengthy waiting times can be avoided entirely since forwarding the defective goods to the manufacturer is no longer necessary! If the graphics card that is to be replaced is out of stock or can no longer be delivered we will issue a credit note to your customer account. With this credit you will be free to select an alternative graphics card from our stock. Any resulting surcharges can be added and we will refund any outstanding balance.

I have a defective graphics card. What do I do now? -> Rapid RMA of faulty graphics cards (click here)

Brands: ASUS, Club 3D, EVGA, Gigabyte, Inno3D, Palit, PNY, Powercolor, Sapphire, VTX3D, XFX, ZOTAC & King Mod

Free Games with AMD Radeon Gaming Graphics Cards:

For every gaming graphics card purchased at Caseking we will send out voucher codes for the current game bundles via e-mail within 14 days after receipt of goods. For products not qualifying for the promotion we will not send out any codes. Only end customers will receive free extras. All promotional campaigns are limited and only valid while stock lasts or until the offer expires. There is no right of appeal. All active AMD voucher codes are listed below:
  • AMD Radeon RX / VII: 3 Months Xbox Game Pass for PC. More Info

Technical Details:
  • Dimensions: 260 x 43 x 135 mm (W × H × D)
    Slot Height: 2-Slot
  • GPU: AMD Radeon RX 570 ("Polaris-20-Pro")
    Manufacturing Process: 14 nm FinFET
    Base Clock: 1.244 MHz
    Boost Clock: max. 1.340 MHz
    Shader Units: 2.048
  • VRAM: 8.192 MB
    Memory Frequency: 3.500 (7.000) MHz
    Type: GDDR5
    Memory Bus Bandwidth: 256 Bit
  • Slot Type: PCIe 3.0 x16
  • Ports:
    2× DisplayPort (V1.4 ready)
    2× HDMI 2.0b
    1× DVI-D Dual-Link
  • TDP: 150 Watt
  • Power Supply: 1× 8-Pin PCIe
    Recommended Power Supply: min. 450 Watt
  • Features: GCN 4. Gen., DirectX 12, Vulkan, OpenGL 4.5, OpenCL 2.1, Mantle, Eyefinity 2.0, CrossFireX, HD3D, TrueAudio, FreeSync 2, HDR-Ready


Further links for "Nitro+ Radeon RX 570 8G, 8192 MB GDDR5"


SAPPHIRE


Videos



Video Thumbnail
Video Thumbnail

Technical Details

GPU type / Series AMD Radeon RX Gaming
Graphics chip AMD Radeon RX 570
Fertigung 14 nm
GPU Takt (Boost) max. 1340 MHz
Shader Einheiten 2048
VRAM size & type 8192 MB GDDR5
Speicher Takt max. 7000 MHz
Speicheranbindung 256 Bit
Display connectors DVI-D, HDMI, HDMI (2x), Display Port, Display Port (2x)
Power supply 1x 8-Pin PCIe
Slot Height 2 Slots
Grafikkarten Länge (exakt) 260 mm
Grafikkarten Höhe (exakt) 43 mm
Grafikkarten Breite (exakt) 135 mm
Grafikkarten Länge 250 - 300 mm
Grafikkarten Höhe 30 - 50 mm
Grafikkarten Breite 130 - 140 mm
Feature AMD FreeSync
