Stealkey Customs SK-UNI 80 D5 - Acrylic
Pump/reservoir combo in black, reservoir with approximately 300 ml capacity, with addressable RGB strip, for Mini-ITX/ATX cases
199,90 €
incl. VAT
, add. delivery costs starting from 4.99€
- Addressable RGB strip included for a custom look
- Versatile options thanks to 10x G1/4-inch ports
- Standard 120 mm fan mounting holes for simple installation (horizontal only)
- High-performance D5 pump pre-installed
- For 120 x 360 mm fan mounts
The SK 80 D5 Pump/Reservoir Combo in Detail
The SK-UNI 80 D5 reservoir-pump combo combines Stealkey's compact yet elegant reservoir with Xylem's powerful D5 pump. Not only is this space-saving, but it also looks impressive.
Addressable RGB Lighting
The UNI 80 offers a stunning look with its excellent addressable RGB lighting. The backlit "STEALKEY" logo is a particular highlight and helps to enhance the appearance of your gaming PC.
Easy Installation
With standard 120mm fan mounting holes, the installation of the UNI 80 D5 is very easy. The included screws ensure a robust, secure hold in the case. There are ten G1/4-inch ports available so you can make your setup as flexible as possible.
- Dimensions: 80 x 120 x 31 mm (W x H x D)
- Colour: Transparent
- Material: Acrylic glass, Plastic
- Connections:
10x G1/4 inch
1x D-RGB connection 3-pin 5V digital LED header (Pin configuration: +5V, D, Blocked, Ground) - Xylem LOWARA D5 PWM Pump:
Dimensions: 65 x 65 x 67 mm (L x W x H)
Design: Electronic ball motor
Materials: Stainless steel 1.4571, PPS-GF40, EPDM O-rings, Aluminium oxide, Hard carbon
Rated voltage: 12 V DC
Power consumption: max. 30 W
Permissible voltage range: 8-24 V DC
Head at 12 V: 3.7 m
Maximum flow rate: 1,500 l/h
Pump medium: Water, Water-Glycol mixtures
Max. system temperature: 60°C
System pressure: max. 1.5 bar
Power connection: 4-pin Molex
Tachometer signal: yes (via 3-pin Molex)
PWM: yes - Scope of delivery:
1x UNI 80
8x Mounting screws incl. 4x nuts
1x Universal adapter for D5 & DDC
1x Spacer mounting strips
8x G1/4 inch plugs
1x LOWARA D5 PWM Pump
|
Colour
|
|
|
Primary Colour
|
Transparent
|
|
Dimensions
|
|
|
Length / Depth
|
31 mm
|
|
Width
|
80 mm
|
|
Height
|
120 mm
|
|
Volume
|
300 ml
|
|
Pump Specifications
|
|
|
Max. Pressure Head
|
3.7 m
|
|
Max. Water Flow
|
1000 l/h
|
|
Type
|
|
|
Pump type
|
DDC
|
|
Power Specifications
|
|
|
Power Consumption
|
18 W
|
|
Rated voltage
|
12 V
|
|
Water Cooling
|
|
|
Water cooling component
|
Pump + Reservoir
|
|
Water cooling connectors
|
10x G1/4"
|
|
Internal Ports
|
|
|
Pump connectors
|
4 Pin (PWM control), Molex (4-Pin) Netzteil
|
|
Materials
|
|
|
Materials
|
Acrylic glass, Plastic
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
| Manufacturer Information | Stealkey Costums - Reger & Gottschalk GbR Neu Roggentiner Straße 3a, 18184 Roggentin, Deutschland |
| Responsible Person | Stealkey Costums - Reger & Gottschalk GbR Neu Roggentiner Straße 3a, 18184 Roggentin, Deutschland |
