Akasa AK-FN078 Slimline PWM Fan - 120mm
designed for HTPC or slim system with limited space
9,90 €
incl. VAT
, add. delivery costs starting from 4.99€
Whether it’s cases, coolers, fans, or cables, Akasa offers a wide range of PC accessories and has enriched the community for many years with innovative and affordable products. The Akasa AK-FN078 Slimline is an excellent 120 mm PWM fan, particularly suited for small cases and HTPCs.
The curved blades of the Akasa AK-FN078 generate an airflow of 92.19 m³/h at a rotational speed of 600 to 1,600 RPM, with a static pressure of 1.36 mm/H2O. The fan operates using an Enter Bearing and reaches a maximum noise level of 30 dB(A) at full speed.
The AK-FN078 is controlled via a PWM signal, allowing it to automatically adjust based on temperature. With a depth of just 15 mm, the fan is slim enough to fit even in very small cases and HTPCs.
|
Colour
|
|
|
Primary Colour
|
Black
|
|
Fan Main Colour (Frame)
|
Black
|
|
Fan Main Colour (Rotor)
|
Black
|
|
Fan Secondary Colour (Rotor)
|
Silver
|
|
Dimensions
|
|
|
Length / Depth
|
120 mm
|
|
Width
|
120 mm
|
|
Fan height
|
15 mm
|
|
Fan Specifications
|
|
|
Fan Size
|
120 mm
|
|
Fan mounting size
|
120 mm
|
|
Fan Blade Direction
|
Standard
|
|
Min. Fan RPM
|
600 rpm
|
|
Max. Fan RPM
|
1600 rpm
|
|
Max. Single Fan Airflow
|
92.19 m³/h
|
|
Max. Static Pressure
|
1.36 mmH2O
|
|
Power Specifications
|
|
|
Rated voltage
|
12 V
|
|
Noise
|
|
|
Max. Single Fan Noise dB(A)
|
30.32 dB(A)
|
|
Internal Ports
|
|
|
Fan connectors
|
4 Pin (PWM)
|
|
Materials
|
|
|
Materials
|
Plastic
|
|
Lighting
|
|
|
Lighting / RGB
|
No
|
