- High-quality finishing with aluminium top plate
- Two Arctic P12 PWM PST CO fans in push-pull operation with easy installation through click system
- Optimised construction with four direct-touch heatpipes, each with 6 mm Ø
- Laterally opened aluminium fins for optimal air intake
- Incl. Intel LGA 1851 / 1700 Contact Frame for even better contact between cooler and CPU
- Compatibility with Intel LGA 1700 / 1851 and AMD AM4 / AM5
- Including powerful MX-6 thermal paste
Improved cooling and design: The new Arctic Freezer 36 CO
Arctic impresses with their new Freezer 36 series: The four direct-touch heatpipes efficiently absorb the CPU's heat, as the cooling surface is directly above the CPU die of the processor. The total of 59 cooling fins made of 0.4 mm thick aluminium are laterally opened allowing the pull fan to draw cool air from the case through the heatsink. This side-flow design achieves even better temperatures.
Proven ventilation with Arctic P12 PWM PST CO fans
Here, the two Arctic P12 PWM PST CO 120mm fans are used in a push-pull configuration, allowing hot air to circulate more quickly out of the heatsink. The Japanese double ball bearings of the fans reduce heat and noise generation while increasing their lifespan. Running at 1,800 RPM, the fans operate quietly while providing effective cooling.
High compatibility and Intel Contact Frame
The Arctic Freezer 36 CO is compatible with Intel socket LGA1700 / 1851 and AMD socket AM4 / AM5. A special Contact Frame for Intel processors only is included in the purchase, ensuring an even more uniform contact between the CPU block and the CPU, resulting in better temperatures. A pack of 0.8g Arctic MX-6 thermal paste is also included.
Choose your favourite version of the new Arctic Freezer 36 CO and enjoy the visually high-quality design with the aluminium top plate, discreetly covering the soldered ends of the heatpipes. Arctic stands for extremely low temperatures at a small price!
- General:
Total weight (with fans): 890g - Dimensions (with fans): 104 x 126 x 159 mm (L x W x H)
- Material: Copper (base, heatpipes), Aluminium (fins)
- Heatpipes: 4x Ø 6mm
- Fans:
Dimensions: 120 x 120 x 25
Quantity: 2x Arctic P12 PWM PST CO
Speed: 200 – 1,800 RPM
Airflow: 95.7m³/h
Static pressure: 2.2 mmH2O
Noise level: 0.3 Sone
Rated voltage: 12V
Rated current: 0.1A
Connectors: 4-pin PWM socket + 4-pin plug - Thermal paste: 0.8g Arctic MX-6
- Compatibility:
AMD socket: AM4 / AM5
Intel socket: 1700 / 1851
Colour
|
|
Primary Colour
|
Silver
|
Secondary Colour
|
Black
|
Fan main colour (cage)
|
Silver
|
Fan main colour (rotor)
|
Black
|
Dimensions
|
|
Length
|
104 mm
|
Width
|
126 mm
|
Height
|
159 mm
|
Weight
|
890 kg
|
Cooler Specifications
|
|
Additional fans possible
|
No
|
Heatpipe diameter
|
6 mm
|
Number of heatpipes
|
4
|
Ventilation type
|
active
|
Type
|
|
CPU Cooler Type
|
Single Tower
|
CPU
|
|
CPU Socket
|
1700, AM4, AM5
|
Fan Specifications
|
|
Min. Fan RPM
|
200 rpm
|
Max. Fan RPM
|
1800 rpm
|
Max. Single Fan Airflow
|
95.7 m³/h
|
Max. Static Pressure
|
2.2 mH2O
|
Noise
|
|
Max. Single Fan Noise dB(A)
|
30 dB(A)
|
Internal Ports
|
|
Fan connectors
|
4 Pin (PWM)
|
Materials
|
|
Materials
|
Aluminium, Copper
|
Base plate material
|
Copper
|
Heat sink material
|
Aluminium
|
Lighting
|
|
Lighting
|
No
|
Set
|
|
Set
|
No
|
Additional Contents
|
|
Included fans
|
2x 120 mm
|
