- Large Big-Tower with support for motherboards up to E-ATX
- Tempered glass side panel
- Supports radiators up to 420 mm on the top panel
- Compatible with GPUs up to 512 mm in length and CPU coolers up to 182 mm in height
- Up to ten fans for maximum cooling performance
- Supports up to two 3.5-inch and four 2.5-inch drives
- Modern I/O panel with USB-C 20 Gbps and combined audio jack
- Includes three 140 mm RGB Momentum fans
Fractal Design Meshify 3 XL: Maximum Performance in a Large Format
The Fractal Design Meshify 3 XL combines a striking mesh design with powerful cooling and a spacious interior. The tempered glass side panel provides a perfect view of your components. Ideal for high-end gaming and custom water cooling, it offers ample space for your build while ensuring efficient heat dissipation.
Massive Cooling Capacity for High-Performance Systems
With support for up to ten fans, the Meshify 3 XL ensures optimal airflow. The front panel accommodates up to three 120 mm or 140 mm fans, with the option for two 180 mm fans. The top panel allows for three additional fans, while the rear supports one 120 mm or 140 mm fan. The bottom panel fits up to three 140 mm fans.
The case is also well-equipped for water cooling: a 360 mm radiator can be mounted at the front, while the top supports radiators up to 420 mm. A side-mounted 360 mm radiator option is also available.
Room for High-End Hardware
The Meshify 3 XL supports motherboards up to the E-ATX standard and offers clearance for GPUs up to 512 mm in length. With a maximum CPU cooler height of 182 mm and PSU clearance of up to 230 mm, this case is perfect for high-performance builds.
Effortless Installation and Clean Cable Management
Thanks to the push-to-lock system, the side panels, front panel, and top panel can be removed with ease. Additionally, the well-thought-out cable management system, featuring cable covers and Velcro straps, ensures a clean setup and improved airflow.
Comprehensive Connectivity Options
The modern I/O panel includes a USB-C port with 20 Gbps, two USB-A ports, and a combined audio jack, ensuring compatibility with the latest peripherals.
|
Colour
|
|
|
Primary Colour
|
Black
|
|
Dimensions
|
|
|
Length / Depth
|
575 mm
|
|
Width
|
245 mm
|
|
Height
|
515 mm
|
|
Weight
|
10.9 kg
|
|
Case
|
|
|
Case Type
|
Full Tower
|
|
Motherboard Support
|
|
|
Compatible Motherboard Formats
|
ATX, E-ATX, EE-ATX, ITX, Micro-ATX, SSI-CEB, SSI-EEB
|
|
Max. Motherboard Format
|
E-ATX
|
|
Internal Dimensions
|
|
|
Max. CPU Cooler Height
|
182 mm
|
|
Max. GPU Length
|
512 mm
|
|
Max. PSU Length / Depth
|
230 mm
|
|
Display
|
|
|
Display Included
|
No
|
|
Power Supply
|
|
|
PSU included
|
No
|
|
PSU Format
|
ATX
|
|
Power Supply Position
|
rear bottom
|
|
Cable Specifications
|
|
|
Riser Cable Included
|
No
|
|
Fan Support
|
|
|
Case Fan Support (Front)
|
120mm Fan (3x), 140mm Fan (3x), 180mm Fan (2x)
|
|
Case Fan Support (Rear)
|
120mm Fan (1x), 140mm Fan (1x)
|
|
Case Fan Support (Side)
|
140mm Fan (3x)
|
|
Case Fan Support (Top)
|
120mm Fan (3x), 140mm Fan (3x)
|
|
Max. Number of Fans
|
10
|
|
120 mm fans
|
7
|
|
140 mm fans
|
10
|
|
180 mm fans
|
2
|
|
Radiator Support
|
|
|
Max. Radiator Compatibility
|
1x Triple (420 mm)
|
|
Radiator/AIO Support (Front)
|
280mm Radiator, 360mm Radiator
|
|
Radiator/AIO Support (Rear)
|
120mm Radiator, 140mm Radiator
|
|
Radiator/AIO Support (Side)
|
360mm Radiator
|
|
Radiator/AIO Support (Top)
|
360mm Radiator, 420mm Radiator
|
|
Drive Bays
|
|
|
Max. 2.5 Inch Drives
|
5
|
|
Max. 3.5 Inch Drives
|
2
|
|
Max. 5.25 Inch Drives
|
0
|
|
2.5 inch internal drive bay
|
4
|
|
3.5 inch internal drive bay
|
2
|
|
Hot swap drive bays
|
Yes
|
|
External Ports
|
|
|
Front I/O – USB Type C Ports Total
|
1
|
|
Front I/O – USB Type A Ports Total
|
2
|
|
USB 3.2 (external) Type C
|
1
|
|
USB 3.0 (external) Type A
|
2
|
|
Audio outputs & inputs
|
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
|
|
Case Features
|
|
|
I/O position
|
Top
|
|
Side panel
|
with window
|
|
Vertical GPU Mount
|
No
|
|
Adjustable Vertical GPU Bracket
|
No
|
|
Front door
|
No
|
|
Cable Management
|
Yes
|
|
Filters Included
|
Yes
|
|
Filter Position
|
Bottom
|
|
Noise dampening
|
No
|
|
Mainboard slide / tray
|
No
|
|
Transport System
|
No
|
|
Back Connect
|
|
|
Back Connect
|
No
|
|
Expansion Slots
|
|
|
Expansion slots / PCI slots
|
7
|
|
Features
|
|
|
Housing Feedthrough
|
No
|
|
Compatibility
|
|
|
Compatibility Note
|
Please refer to the manufacturer's compatibility information. You can find the latest overview on the manufacturer's website.
|
|
Connectivity
|
|
|
Card reader
|
No
|
|
Fan Header
|
|
|
Fan Controller / Fan Hub
|
No
|
|
Mounting
|
|
|
Case VESA Mountable
|
No
|
|
Internal Monitor Mount
|
No
|
|
Materials
|
|
|
Materials
|
Steel, Tempered Glass
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
|
RGB Controller
|
No
|
|
Additional Contents
|
|
|
Fans Included
|
Yes
|
|
Included fans
|
3x 140 mm
|
