- Stylish case with side panel and front made of tempered glass and wood finish
- Efficient cooling options with up to nine fans and radiators up to 360 mm
- Support for motherboards up to Micro-ATX
- Space for graphics cards up to 410mm and CPU coolers with a height of up to 160mm
- Independent cooling for GPU / CPU as well as power supply and drives
- Up to three drives possible
- Three 120mm fans included
The Antec CX600M Wood: Mini-tower with plenty of space
The Antec CX600M Wood stands out at first glance from other mini-towers: Despite its small size and light weight, it offers you an incredible number of options to install your high-end hardware. Additionally, the tempered glass on the side and front allows a view into the interior - so the RGB lighting of your gaming PC is perfectly showcased. A wood finish on the side front gives the case an elegant flair.
Excellent cooling performance
The Antec CX600M Wood supports up to nine fans to optimally cool even the most powerful hardware. On the top, three 120mm or two 140mm fans can be installed. On the side, you can install two 120mm or 140mm fans. At the bottom under the fan, there is space for a total of three more 120mm fans, and an additional one can be mounted at the back. Three 120mm PWM ARGB fans are already built into the tower, of which two are reverse fans on the side and one is in a normal orientation at the back.
If you prefer water cooling - whether an all-in-one water cooler or a custom-built cooling system - there are several locations where a radiator can be installed. The top and bottom each support a radiator up to a maximum of 360mm, a maximum 280mm radiator can be installed on the side, as well as a 120mm radiator at the back.
The cooling of your system is further enhanced by the mesh covers on the bottom, side, and top. The dual-chamber design also improves airflow - in one chamber, the CPU and GPU are cooled, while the power supply and drives are in the other.
Extensive hardware options
The mini-tower supports the installation of large graphics cards up to a size of 410mm. Motherboards are feasible up to the Micro-ATX format. The CPU cooler should not exceed a height of 160mm, and the power supply should not be longer than 240mm. To store programs and games, up to three drives can be installed.
Colour
|
|
Primary Colour
|
Black
|
Dimensions
|
|
Length / Depth
|
436 mm
|
Width
|
290 mm
|
Height
|
370 mm
|
Weight
|
6.25 kg
|
Case
|
|
Case Type
|
Mini Case
|
Motherboard Support
|
|
Compatible Motherboard Formats
|
ITX, Micro-ATX
|
Max. Motherboard Format
|
Micro-ATX
|
Internal Dimensions
|
|
Max. CPU Cooler Height
|
160 mm
|
Max. GPU Length
|
410 mm
|
Max. PSU Length / Depth
|
240 mm
|
Display
|
|
Display Included
|
No
|
Power Supply
|
|
PSU included
|
No
|
PSU Format
|
ATX
|
Power Supply Position
|
bottom
|
Fan Support
|
|
120 mm fans
|
9
|
140 mm fans
|
4
|
Radiator Support
|
|
Max. Radiator Compatibility
|
1x Dual (280 mm), 1x Single (120 mm), 2x Triple (360 mm)
|
Drive Bays
|
|
2.5 inch internal drive bay
|
2
|
3.5 inch internal drive bay
|
1
|
External Ports
|
|
USB 3.1 (external) Type C
|
1
|
USB 2.0 (external) Type A
|
1
|
Audio outputs & inputs
|
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
|
Case Features
|
|
I/O position
|
Cover
|
Side panel
|
with window
|
Filters Included
|
Yes
|
Expansion Slots
|
|
Expansion slots / PCI slots
|
5
|
Materials
|
|
Materials
|
Steel, Tempered Glass, Wood
|
Lighting
|
|
Lighting / RGB
|
Yes
|
Additional Contents
|
|
Included fans
|
3x 120 mm
|
