ASROCK B860M Challenger WiFi Motherboard, Socket 1851, Intel B860, mATX, DDR5
Micro-ATX motherboard with B860 chipset, 1x PCIe 5.0 x16 / 1x PCIe 4.0 x4, 1x USB-C / 5x USB-A, 3x M.2 (1x PCIe 5.0 / 2x PCIe 4.0) / 4x SATA 6G, up to 256 GB DDR5-8666 RAM
139,90 €
Incl. VAT, add. delivery costs starting from 4.99€
- Slots: 1x PCIe 5.0 x16 (x16) and 1x PCIe 4.0 x4 (x4)
- RAM: 4x DIMM slots for up to 256 GB DDR5 RAM up to 8,666 MT/s
- Storage: 3x M.2 (1x PCIe 5.0 & 2x PCIe 4.0) and 4x SATA
- USB: 1x USB-C 3.0, 3x USB 3.0 and 2x USB 2.0
- Cooling: 6x 4-pin PWM connectors for fans and pumps
- Connectivity: Wi-Fi 7 and Bluetooth 5.4
ASROCK B860M Challenger WiFi: Micro-ATX motherboard with Intel LGA 1851 socket and B860 chipset
The ASROCK B860M Challenger WiFi is a Micro-ATX motherboard featuring the mid-range Intel B860 chipset and Intel LGA 1851 socket. It supports Intel processors from the Arrow Lake generation and is suitable for gamers who can forego CPU overclocking.
Additionally, the B860 motherboards support WiFi 7, enabling very fast data transfer rates completely wirelessly. The MSI B860M Gaming Plus WiFi also offers PCIe 5.0 for graphics cards and M.2 SSDs. The DDR5 memory is also overclockable, allowing you to get the best out of your RAM.
|
Colour
|
|
|
Primary Colour
|
Black
|
|
Dimensions
|
|
|
Length / Depth
|
24.4 mm
|
|
Width
|
24.4 mm
|
|
Form Factor
|
|
|
Motherboard Form Factor
|
Micro-ATX
|
|
CPU
|
|
|
CPU Manufacturer
|
Intel
|
|
CPU Socket
|
1851
|
|
Display
|
|
|
Display Included
|
No
|
|
Power Specifications
|
|
|
Power Stages (VRMs)
|
10+1+1+1+1
|
|
Motherboard
|
|
|
BIOS Flashback Button
|
No
|
|
Clear CMOS Button
|
No
|
|
Motherboard Chipset
|
Intel B860
|
|
Motherboard Features
|
Debug LEDs, M.2 Quick Release
|
|
Dual BIOS
|
No
|
|
Built-In I/O Shield
|
Yes
|
|
Memory
|
|
|
Max. Memory
|
256 GB
|
|
Memory Type
|
DDR5
|
|
Memory Form Factor
|
DIMM
|
|
System Memory Subtype
|
CUDIMM, UDIMM
|
|
Max. Memory Speed (Standard)
|
5600 MT/s
|
|
Max. Memory Speed (OC)
|
8666 MT/s
|
|
EEC Support
|
No
|
|
Memory slots
|
4x
|
|
Performance Profile
|
AMD EXPO, Intel XMP 3.0
|
|
Wi-Fi & LAN
|
|
|
LAN
|
Yes
|
|
LAN Ports
|
1x 2.5 Gbit/s
|
|
Wi-Fi / Bluetooth
|
Yes
|
|
Wi-Fi Standard
|
Wi-Fi 7
|
|
Bluetooth Standard
|
5.4
|
|
Cooling
|
|
|
Backplate
|
No
|
|
M.2 Heatsinks
|
Yes
|
|
VRM Heatsinks
|
Yes
|
|
Water Cooling
|
|
|
Watercooling
|
No
|
|
Internal Ports
|
|
|
CPU Power Supply
|
1x 4-Pin + 1x 8-Pin
|
|
USB 3.0 / 3.1 / 3.2 (internal) Type C Header
|
1
|
|
USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports
|
1
|
|
USB 3.0 (internal) Header
|
1
|
|
USB 3.0 (internal) Possible Ports
|
1
|
|
USB 2.0 (internal) Header
|
2
|
|
USB 2.0 (internal) Possible Ports
|
4
|
|
RGB / LED connectors
|
1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG)
|
|
Front Panel Audio Header
|
Yes
|
|
SPI TPM Header
|
Yes
|
|
External Ports
|
|
|
USB 3.2 (external) Type C
|
1
|
|
USB 3.2 (external) Type A
|
3
|
|
USB 2.0 (external) Type A
|
2
|
|
Display Connectors
|
HDMI (1x)
|
|
Audio outputs
|
3.5 mm jack (total) 3x
|
|
Storage Ports
|
|
|
M.2 PCIe 4.0 x4
|
2
|
|
M.2 PCIe 5.0 x4
|
1
|
|
M.2 E-Key
|
1
|
|
SATA 6G (internal)
|
4
|
|
Back Connect
|
|
|
Back Connect
|
No
|
|
Expansion Slots
|
|
|
PCIe x16 slots (total)
|
1
|
|
PCIe x4 slots (total)
|
1
|
|
PCIe 5.0 x16 mechanical slot
|
1
|
|
PCIe 4.0 x4 mechanical slot
|
1
|
|
Compatibility
|
|
|
Compatibility Note
|
Please refer to the manufacturer's compatibility information. You can find the latest overview on the manufacturer's website.
|
|
Fan Header
|
|
|
4 Pin Fan Connectors
|
6
|
|
Audio
|
|
|
Soundchip
|
Realtek ALC897
|
|
Lighting
|
|
|
Lighting / RGB
|
No
|
