ASRock Z890 LiveMixer WiFi, Intel Z890 motherboard, socket LGA 1851, Intel Z890, ATX, DDR5
ATX-Mainboard with Intel Z890 chipset, 1x PCIe 5.0 x16 / 2x PCIe 4.0 x16, 2x USB4 / 2x USB 3.1 / 10x USB 3.0, 4x M.2 (1x PCIe 5.0, 3x PCIe 4.0) / 4x SATA 6G, 8x 4-Pin PWM connectors
Intel® Motherboard Bundle
More detailsUnlock one game with purchase of a qualifying Intel® Z890 or B860 chipset motherboard – choose one of three titles.
OFFER ENDS31.12.2026
REDEEM BY31.01.2027
*You will receive your Master Key together with the redemption instructions after purchase. Redeem at softwareoffer.intel.com.
231,53 €
Incl. VAT, add. delivery costs starting from 4.99€
This motherboard is ideal for content creators and gamers.
- 1x PCIe 5.0 x16 (x16), 2x PCIe 4.0 x16 (x4)
- 4x DIMM slots for up to 256 GB DDR5 RAM at 9,066 MHz (XMP 3.0 support)
- 4x M.2 (including 1x PCIe 5.0 and 3x PCIe 4.0) / 4x SATA 6G
- USB on I/O panel: 2x USB4, 2x USB 3.1, 10x USB 3.0
- OC features: 18+1+1+1+1 power phases, enlarged heatsinks
- In total, 8x 4-pin connectors for fans & pumps
ASROCK Z890 LIVEMIXER WIFI: ATX-Mainboard with Intel LGA 1851 socket and Z890 chipset
The ASROCK Z890 LIVEMIXER WIFI is an ATX motherboard with the high-end Intel Z890 chipset and the LGA 1851 socket. It supports Intel Core Ultra processors of the second generation with the codename Arrow Lake. The Intel Z890 motherboard natively supports USB4, offering data transfer rates of up to 40 Gbit/s. Additionally, the ASROCK Z890 LIVEMIXER WIFI features full PCIe 5.0 connectivity, providing double the bandwidth for graphics cards and NVMe SSDs compared to PCIe 4.0.
- Form factor:
ATX (305 x 244 mm) - Chipset:
Intel Z890 - Socket:
LGA 1851 (For Intel Core Ultra CPUs of the 2nd generation) - RAM:
4x DDR5 DIMM (up to 9,066 MHz via XMP)
Dual-Channel
Max. 256 GB - Slots (physical):
1x PCIe 5.0 x16 (electrical x16 or x8/x8)
2x PCIe 4.0 x16 (electrical x4) - Total usable PCIe lanes: 44
- Internal connectors:
4x SATA 6G (max.)
1x M.2 (PCIe 5.0 x4, 2280, CPU)
1x M.2 (PCIe 4.0 x4, 2280, CPU)
1x M.2 (PCIe 4.0 x4, chipset)
1x M.2 (PCIe 4.0 x4, chipset)
1x USB-C (1 header, USB 3.2 Gen 2x2, max. 20 Gbit/s)
2x USB 3.0 (1 header, USB 3.2 Gen 1, max. 5 Gbit/s)
2x USB 2.0 (1 header, max. 480 Mbit/s)
1x Front Panel Audio header
1x Front System Panel header
1x Thermal Sensor header - Fan headers:
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x 4-pin AIO Pump header
5x case fans (4-pin) - External connectors:
2x Thunderbolt 4 (USB-C 40 Gbit/s)
2x USB 3.1 (Type-A, USB 3.2 Gen 2, max. 10 Gbit/s)
10x USB 3.0 (Type-A, USB 3.2 Gen 1, max. 5 Gbit/s)
1x HDMI
1x 2.5 Gigabit LAN
1x WiFi/Bluetooth module
2x 3.5 mm jacks (Realtek ALC 4080)
1x S/PDIF Audio - Power supply:
1x 24-pin ATX
2x 8-pin ATX12V
1x 6-pin PCIe ATX
|
Colour
|
|
|
Primary Colour
|
Black
|
|
Dimensions
|
|
|
Length / Depth
|
305 mm
|
|
Width
|
244 mm
|
|
Form Factor
|
|
|
Motherboard Form Factor
|
ATX
|
|
CPU
|
|
|
CPU Manufacturer
|
Intel
|
|
CPU Socket
|
1851
|
|
Motherboard
|
|
|
Motherboard Chipset
|
Intel Z890
|
|
Built-In I/O Shield
|
Yes
|
|
Memory
|
|
|
Max. Memory
|
256 GB
|
|
Memory Type
|
DDR5
|
|
Memory Form Factor
|
DIMM
|
|
Max. Memory Speed (OC)
|
9066 MT/s
|
|
Memory slots
|
4x
|
|
Performance Profile
|
Intel XMP 3.0
|
|
Wi-Fi & LAN
|
|
|
LAN
|
Yes
|
|
LAN Ports
|
1x 2.5 Gbit/s
|
|
Wi-Fi / Bluetooth
|
Yes
|
|
Wi-Fi Standard
|
Wi-Fi 7
|
|
Cooling
|
|
|
Backplate
|
No
|
|
M.2 Heatsinks
|
Yes
|
|
VRM Heatsinks
|
Yes
|
|
Internal Ports
|
|
|
CPU Power Supply
|
2x 8-Pin
|
|
USB 3.0 / 3.1 / 3.2 (internal) Type C Header
|
1
|
|
USB 3.0 (internal) Header
|
2
|
|
USB 2.0 (internal) Header
|
2
|
|
Front Panel Audio Header
|
Yes
|
|
External Ports
|
|
|
USB4 Gen 3x2 (external) Type C
|
2
|
|
USB 3.1 (external) Type A
|
2
|
|
USB 3.0 (external) Type A
|
10
|
|
Storage Ports
|
|
|
M.2 PCIe 4.0 x4
|
3
|
|
M.2 PCIe 5.0 x4
|
1
|
|
SATA 6G (internal)
|
4
|
|
Back Connect
|
|
|
Back Connect
|
No
|
|
Expansion Slots
|
|
|
PCIe x16 slots (total)
|
3
|
|
PCIe 5.0 x16 mechanical slot
|
1
|
|
PCIe 4.0 x16 mechanical slot
|
2
|
|
Fan Header
|
|
|
4 Pin Fan Connectors
|
8
|
|
Audio
|
|
|
Soundchip
|
Realtek ALC1220
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
