ATX motherboard with Intel Z890 chipset, 2x PCIe 5.0 x16 / 2x PCIe 4.0 x4, 2x USB4 / 2x USB 3.1 / 4x USB 3.0 / 2x USB 2.0, 4x M.2 (1x PCIe 5.0, 2x PCIe 4.0, 1x PCIe 4.0 & SATA) / 4x SATA 6G, 8x 4-pin PWM connectors
292,11 €
incl. VAT , add. delivery costs starting from 4.99€
SKU MBAR-497 |
EAN 4710483947520 |
MPN 90-MXBPF0-A0UAYZ |
Manufacturer ASRock

This motherboard is excellent for high-end builds.

  • 1x PCIe 5.0 x16 (x16), 1x PCIe 4.0 x16 (x4) and 1x PCIe 4.0 x4 (x4)
  • 4x DIMM slots for max. 256GB DDR5 RAM up to 9,066MHz (XMP 3.0)
  • 4x M.2 (including 1x PCIe 5.0, 2x PCIe 4.0 and 1x PCIe 4.0 & SATA) / 4x SATA 6G
  • USB on I/O panel: 2x USB4, 2x USB 3.1, 4x USB 3.0 and 2x USB 2.0
  • OC features: 18+1+1+1+1 phase VRMs, BIOS flashback
  • A total of 8x 4-pin connectors for fans & pumps

ASROCK Z890 STEEL LEGEND WIFI: ATX motherboard with Intel LGA 1851 socket and Z890 chipset

The ASROCK Z890 STEEL LEGEND WIFI is an ATX motherboard featuring the high-end Intel Z890 chipset and LGA 1851 socket. It supports Intel Core Ultra processors of the second generation with the codename Arrow Lake. The Intel Z890 motherboard natively supports USB4, which offers data transfer rates of up to 40Gbit/s. Additionally, the ASROCK Z890 STEEL LEGEND WIFI impresses with full PCIe 5.0 connectivity, providing you with double the bandwidth for graphics cards and NVMe SSDs compared to PCIe 4.0.

  • Form factor:
    ATX (305 x 244 mm)
  • Chipset:
    Intel Z890
  • Socket:
    LGA 1851 (For Intel Core Ultra CPUs of the 2nd generation)
  • RAM:
    4x DDR5 DIMM (up to 9,066 MHz via OC)
    Dual-Channel
    Max. 256 GB
  • Slots (physical):
    1x PCIe 5.0 x16 (electrical x16, CPU)
    1x PCIe 4.0 x16 (electrical x4, chipset)
    1x PCIe 4.0 x4 (electrical x4, chipset)
  • Total maximum usable PCIe lanes: 44
  • Internal connections:
    4x SATA 6G (max.)
    1x M.2 (PCIe 5.0 x4; 2280, CPU)
    1x M.2 (PCIe 4.0 x4; 2280, CPU)
    1x M.2 (PCIe 5.0 x4 & SATA; 2280, chipset)
    1x M.2 (PCIe 4.0 x4; 2230 / 2242 / 2260 / 2280, chipset)
    1x USB-C (1 Header, USB 3.2 Gen 2x2, max. 20 Gbit/s)
    4x USB 3.0 (2 Headers, USB 3.2 Gen 1, max. 5 Gbit/s)
    4x USB 2.0 (2 Headers, max. 480 Mbit/s)
    1x Front Panel Audio Header
  • Fan headers:
    2x CPU-Fan (4-Pin)
    1x W_PUMP+ Header
    5x Case fans (4-Pin)
  • RGB headers:
    3x 3-Pin ARGB (5 V)
    1x 4-Pin RGB (12 V)
  • External connections:
    2x Thunderbolt 4 (USB-C)
    2x USB 3.1 (Type A, USB 3.2 Gen 2, max. 10 Gbit/s)
    4x USB 3.0 (Type A, USB 3.2 Gen 1, max. 5 Gbit/s)
    2x USB 2.0 (Type C, max. 480 Mbit/s)
    2x Antenna port
    1x HDMI
    1x 2.5 Gigabit LAN (Dragon RTL8125BG)
    1x WiFi/Bluetooth module (Wi-Fi 7)
    2x 3.5 mm jack (Realtek ALC 1220)
    1x S/PDIF Audio
  • Power supply:
    1x 24-Pin ATX
    2x 8-Pin ATX12V
  • Accessories:
    2 x SATA data cables
    2 x ASRock WiFi 2.4/5/6 GHz antennas
    1 x Thermistor cable
Colour
Primary Colour
White
Form Factor
Motherboard formfactor
ATX
CPU
CPU Manufacturer
Intel
CPU Socket
1851
Motherboard
Motherboard Chipset
Intel Z890
Memory
Max. Memory
256 GB
Memory Type
DDR5
Memory Form Factor
DIMM
Max. Memory Speed (OC)
9066 MT/s
Memory slots
4x
Performance Profile
Intel XMP 3.0
Wi-Fi & LAN
LAN
Yes
LAN Ports
1x 2.5 Gbit/s
Wi-Fi / Bluetooth
Yes
Wi-Fi Standard
Wi-Fi 7
Bluetooth Standard
5.4
Cooling
VRM Heatsinks
Yes
Internal Ports
CPU Power Supply
2x 8-Pin
USB 3.0 / 3.1 / 3.2 (internal) Type C Header
1
USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports
1
USB 3.0 (internal) Header
2
USB 3.0 (internal) Possible Ports
4
USB 2.0 (internal) Header
2
USB 2.0 (internal) Possible Ports
4
RGB / LED connectors
1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG)
Front Panel Audio Header
Yes
SPI TPM Header
No
External Ports
USB4 Gen 3x2 (external) Type C
2
USB 3.1 (external) Type A
2
USB 3.0 (external) Type A
4
USB 2.0 (external) Type A
2
Storage Ports
M.2 PCIe 4.0 x4
1
M.2 PCIe 4.0 x4 & SATA 6G
1
M.2 PCIe 5.0 x4
1
M.2 PCIe 5.0 x4 & SATA 6G
1
SATA 6G (internal)
4
Expansion Slots
PCIe x16 slots (total)
2
PCIe x4 slots (total)
1
Fan Header
4 Pin Fan Connectors
8
Audio
Soundchip
Realtek ALC1220
Lighting
Lighting / RGB
Yes
