- Midi tower for motherboards up to E-ATX
- Suitable for radiators up to 360 mm
- Space for graphics cards up to 422 mm in length
- Up to ten fans possible for optimal cooling
- Can accommodate four 2.5 / 3.5-inch drives
Exceptional Design
At first glance, the Y70 by Hyte impresses with its three-part panoramic tempered glass window, providing a 360-degree view of your hardware. This allows you to showcase your PC build perfectly. At the same time, built-in fan slots at the bottom and on the side of the midi tower ensure optimal airflow.
Efficient Cooling
In addition to the design that ensures unobstructed airflow, you can optimally cool your hardware with fans or radiators. The top supports a radiator up to 360 mm, but it must not be taller than 68 mm. There is also space on the side for a 280 mm or 360 mm radiator, which can be up to 125 mm high. Additionally, you can place a 120 mm or 140 mm radiator at the back, for example for a small all-in-one water cooling system.
Furthermore, up to ten fans can be installed. You can fit either three 120 mm or two 140 mm fans on the top. At the rear, a 120 mm or 140 mm fan can be installed. You can also install up to three 120 mm or two 140 mm fans at the bottom, provided they are no higher than 32 mm. On the side, there is space for three 120 mm or two 140 mm fans. Your hardware will therefore definitely not overheat.
Ample Space for Components
Thanks to its large build, you can mount motherboards up to E-ATX. The case supports the installation of graphics cards up to a length of 422 mm. This means you can easily install high-end graphics cards from NVIDIA or AMD. Additionally, this can be done both horizontally and vertically, as long as the graphics card does not require more than four slots. The riser cable needed for this is included. The CPU height must not exceed 180 mm, and the length of the ATX power supply must be no more than 235 mm.
To provide sufficient storage for your games and programmes, you can install up to four 2.5-inch drives or two 3.5-inch drives. The I/O panel features a fast USB-C 3.2 port, as well as two USB-A ports and an audio/mic connection.
Technical Details
- Colour: White
- Dimensions: 320 x 470 x 470 mm (W x H x D)
- Form Factor: E-ATX, ATX, Micro-ATX, ITX
- Drives:
4x 2.5 / 2x 3.5 inches - Radiator Mountings:
1x max. 280 / 360 mm (top, up to 68 mm height)
1x max. 120 / 140 mm (rear)
1x max. 280 / 360 mm (side, up to 125 mm height) - Total Fans Possible:
3x 120 / 2x 140 mm (top)
1x 120 / 140 mm (rear)
3x 120 / 2x 140 mm (bottom, up to 32 mm height)
3x 120 / 2x 140 mm (side) - Power Supply: ATX 12 V (up to 235 mm PSU length)
- Expansion Slots: 7 horizontal, 4 vertical
- I/O Panel:
1x USB-C 3.2 (Gen 2)
2x USB 3.2
1x Audio / Mic - Maximum CPU cooler height: 180 mm
- Maximum graphics card length: 422 mm
Colour
|
|
Primary Colour
|
White
|
Dimensions
|
|
Length / Depth
|
470 mm
|
Width
|
320 mm
|
Height
|
470 mm
|
Case
|
|
Case Type
|
Mid Tower
|
Motherboard Support
|
|
Compatible Motherboard Formats
|
ATX, E-ATX, Micro-ATX, Mini-ITX
|
Max. Motherboard Format
|
E-ATX
|
Internal Dimensions
|
|
Max. CPU Cooler Height
|
180 mm
|
Max. GPU Length
|
422 mm
|
Max. PSU Length / Depth
|
235 mm
|
Power Supply
|
|
PSU included
|
No
|
PSU Format
|
ATX
|
Fan Support
|
|
120 mm fans
|
10
|
140 mm fans
|
7
|
Radiator Support
|
|
Max. Radiator Compatibility
|
360
|
Drive Bays
|
|
1x 3.5 / 1x 2.5 Inch Internal Drive Bays (combined)
|
4
|
External Ports
|
|
USB 3.2 (external) Type C
|
1
|
USB 3.0 (external) Type A
|
2
|
Audio outputs & inputs
|
1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
|
Case Features
|
|
I/O position
|
Front
|
Side panel
|
with window
|
Filters Included
|
Yes
|
Expansion Slots
|
|
Expansion slots / PCI slots
|
7
|
Lighting
|
|
Lighting / RGB
|
No
|
Fan / RGB control
|
No
|
Product Series
|
|
Product Series/Family
|
Y70
|
Additional Contents
|
|
Included fans
|
None
|
