AMD Radeon RX 9060 XT 8 GB Graphics Cards (RDNA-4)
The AMD Radeon RX 9060 XT 8 GB delivers powerful graphics performance for Full HD gaming at high settings. Thanks to the efficient RDNA 4 architecture, the graphics card reaches boost clock speeds of up to 3.1 GHz, ensuring stable frame rates in every game. With AMD FSR 4, ray tracing, and GDDR6 memory, you’ll enjoy smooth visuals and stunning lighting and shadow effects!
View:
6 Results
AMD Radeon RX 9060 XT Graphics Card: Smooth Gaming in Sharp Full HD Resolution
Thanks to RDNA 4 architecture, modern game titles are no challenge for the AMD Radeon RX 9060 XT 8 GB. Its 32 ray tracing cores deliver impressively realistic lighting, shadow, and reflection effects—making you feel like you're right in the middle of the action.
Key Specifications of the AMD Radeon RX 9060 XT 8 GB (Reference Design)
- Compute Performance: 25.6 teraflops
- Ray Tracing Cores: 32
- Base Clock: 2,530 MHz
- Boost Clock: 3,130 MHz
- Graphics Memory: 8 GB GDDR6
- Memory Speed: 20 Gbps
- Memory Interface: 128-bit
- Memory Bandwidth: 320 GB/s
- TDP: 150 watts
- Power Connector: 1x 8-pin
- Video Outputs: 2x DisplayPort 2.1a, 1x HDMI 2.1b
RX 9060 XT 8 GB With AMD FidelityFX Super Resolution 4 for Maximum FPS
The RX 9060 XT GPU supports the new FSR 4 and leverages advanced AI-based upscaling to significantly boost frame rates—even in demanding games, everything runs smoothly without compromise.
The Navi 44 GPU in the AMD Radeon RX 9060 XT delivers a base clock of 2,530 MHz and a boost clock of up to 3,130 MHz. Even at high clock speeds, this card maintains efficient power consumption thanks to the RDNA 4 architecture.
System Requirements for the AMD Radeon RX 9060 XT 8 GB
- Motherboard with a PCIe 5.0 x16 slot (backwards compatible)
- Dimensions vary by manufacturer
- 450 W or higher power supply unit (PSU)
- Up to 3 free expansion slots
- One 8-pin PCIe connector
- 8 GB RAM (16 GB recommended)
- Internet connection required
- Microsoft Windows® 10 64-bit, Windows® 11 64-bit, or Linux 64-bit
Technology Support
- AMD Architecture: RDNA 4
- Ray Tracing: Yes
- AMD FidelityFX Super Resolution: FSR 4
- AMD Radeon Anti-Lag 2: Yes
- AMD Fluid Motion Frames 2: Yes
- PCI Express Gen 5: Yes
- AMD FreeSync: Yes
- DirectX 12 Ultimate: Yes
- OpenGL 4.6: Yes
- AV1 Encoding: Yes
- AV1 Decoding: Yes
- VR Ready: Yes
Display Support
- Maximum Resolution: 4K at 240 Hz or 8K at 60 Hz
- Display Ports: 2x DisplayPort 2.1a, 1x HDMI 2.1b
- Multi-Monitor Support: Up to 3 monitors
- HDCP: 2.3
Thermal and Power Specifications
- Total Graphics Power (TDP): 150 W
- Recommended System Power: 450 W
- Additional Power Connectors: 1x 8-pin
AMD Radeon RX 9060 XT 8 GB FAQ
What Resolutions Are Supported by the AMD Radeon RX 9060 XT 8 GB?
The AMD Radeon RX 9060 XT 8 GB graphics card handles your favourite games smoothly in Full HD (1,920 x 1,080).
Can I Play VR Games With the AMD Radeon RX 9060 XT 8 GB?
Popular VR games run at fluid frame rates and medium settings with the RX 9060 XT 8 GB.
Will the AMD Radeon RX 9060 XT 8 GB Fit in My Case?
Card size depends on the model and fan configuration. Be sure to check your case and GPU dimensions before purchase.
What PSU Do I Need for the AMD Radeon RX 9060 XT 8 GB?
A power supply with a single 8-pin port is sufficient. For consistent performance, a PSU with at least 450 watts is recommended.
What Display Outputs Does the AMD Radeon RX 9060 XT 8 GB Have?
Standard ports include one HDMI 2.1b and two DisplayPort 2.1a connectors—supporting up to three displays simultaneously.
