Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo - white
- Combination of reservoir and D5 PWM pump
- Can be installed in any case with 360 mm or 3x 120 mm fan slots
- Fill and drain ports for easy filling and draining of liquid
- Quiet, efficient, and decoupled for minimal noise levels
- Check cooling performance easily with the temperature sensor
- Combination of acrylic glass and nylon makes it heat- and impact-resistant
- iCUE-compatible RGB lighting with 36 digitally addressable LEDs
- Transparent reservoir with 140 ml capacity
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo in Detail
Corsair says with the Hydro X Series XD7 RGB Pump and Reservoir Combo: "Everything in one, please." It offers you a powerful 360 mm distribution plate with D5 PWM pump, exciting RGB lighting effects, and a temperature sensor, making it perfect for driving demanding cooling systems.
Powerful Cooling System: Universal 360 mm Distribution Plate
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo fits into all cases that support a 360 mm radiator size. It is the heart of any water cooling system as it connects all components and drives the flow. With PWM control, it all happens automatically – no need for manual adjustments.
Liquid can be easily filled or drained. The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo includes integrated fill and drain ports. It also features a temperature sensor, providing real-time information on the status of your cooling loop or showing its temperature. The iCUE Commander PRO controls the cooling via the iCUE software, optimising it for maximum efficiency.
Durable and Bold Design with Stunning RGB Lighting
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo is heat- and impact-resistant thanks to the combination of acrylic glass and nylon. This not only gives it durability but also makes it transparent, allowing you to enjoy the vibrant colours from the liquid or RGB lighting at all times.
To keep it as quiet as possible, decouplers are included in the mounting system, minimising pump vibrations transferred to the case.
36 individually addressable RGB LEDs make all your colour effect dreams come true, beautifully highlighting the reservoir with its 140 ml capacity.
Note: When combined with a CORSAIR iCUE controller, you can customise and synchronise all the RGB LEDs for all iCUE-compatible products. This must be purchased separately.
- Combination of expansion tank and D5 PWM pump
- Can be installed in any case with 360 mm or 3x 120 mm fan slots
- Fill and drain port for easy filling and draining of liquid
- Quiet, efficient and decoupled for minimal noise levels
- Cooling performance can be easily checked with the temperature sensor
- Combination of acrylic glass and nylon makes it heat and shock resistant
- iCUE-compatible RGB lighting with 36 digitally addressable LEDs
- Transparent expansion tank with 140 ml capacity
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo in Detail
Corsair says with the Hydro X Series XD7 RGB pump and tank combination: "All in one, please." It offers you a powerful 360 mm distribution plate with D5 PWM pump, exciting RGB lighting effects and a temperature sensor. This drives demanding cooling systems.
Powerful Cooling System: Universal 360 mm Distribution Plate System
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo fits into all cases that support a radiator size of 360 mm. It is the centre of any water cooling system because it connects all components and drives the flow. With PWM control, this happens automatically - you don't have to do anything else.
The liquid can be easily filled or drained. The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo has an integrated fill and drain port. It also features a temperature sensor. It keeps you informed at all times about the status of your cooling loop or shows you its temperature. The iCUE Commander PRO controls the cooling and elevates it to the most efficient level using the iCUE software.
Robust and Unique Design with Wild RGB Lighting
The Corsair Hydro X Series XD7 RGB D5 Pump Reservoir Combo is heat and shock resistant thanks to the mix of acrylic glass and nylon. This not only gives it durability but also makes it transparent. You can see all the vibrant colours that water cooling has to offer at any time - in the liquid or RGB lighting.
To keep it as quiet as possible, decouplers have been attached to the mounting system. This minimizes the pump vibration that is transmitted to the case.
Note: In combination with a CORSAIR iCUE controller, you can customise and synchronise all RGB LEDs for all iCUE-compatible products. This must be purchased separately.
|
Colour
|
|
|
Primary Colour
|
White
|
|
Secondary Colour
|
Transparent
|
|
Dimensions
|
|
|
Length / Depth
|
93 mm
|
|
Width
|
120 mm
|
|
Height
|
37693 mm
|
|
Volume
|
140 ml
|
|
Pump Specifications
|
|
|
Max. Pressure Head
|
2.1 m
|
|
Max. Water Flow
|
800 l/h
|
|
Type
|
|
|
Pump type
|
D5
|
|
Power Specifications
|
|
|
Power Consumption
|
30 W
|
|
Rated voltage
|
12 V
|
|
Water Cooling
|
|
|
Water cooling component
|
Pump + Reservoir
|
|
Water cooling connectors
|
9x G1/4"
|
|
Internal Ports
|
|
|
Pump connectors
|
4 Pin (PWM control), Molex (4-Pin) Netzteil
|
|
RGB / LED connectors
|
1x Digital RGB (3-Pin 5VDG), yes
|
|
Thermal Specifications
|
|
|
Max. System Temperature
|
60 °C
|
|
Materials
|
|
|
Materials
|
PMMA, POM
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
|
Lighting Colour
|
RGB
|
