EK Water Blocks EK-Quantum Kinetic3 FLT D5 PWM Reservoir-Pump Combo - 280mm, D-RGB, Acrylic
- 445-ml pump-reservoir combo for high-end systems
- Easy maintenance and flexibility thanks to eight G1/4-inch fittings
- High-quality acrylic glass for clear visibility of your coolant
- D-RGB lighting for customisable lighting effects
- Integrated D5 PWM pump for maximum cooling performance
- Durable EPDM O-rings for maximum reliability
- Easy installation thanks to 140-mm fan mounting holes
The EK-Quantum Kinetic3 FLT D5 PWM D-RGB Reservoir-Pump Combo in Detail
The EK-Quantum Kinetic3 FLT D5 PWM D-RGB stands out with its integrated D5 PWM pump and high-quality construction. With a maximum flow rate of 1.000 l/h and a maximum head pressure of 5.2 m, the pump delivers substantial power, ensuring your system remains well-cooled.
The reservoir is made from transparent acrylic glass, providing excellent visibility of your coolant. The integrated addressable D-RGB lighting, concealed behind a black anodised aluminium cover, offers even illumination.
With a volume of 445 ml, this reservoir is ideal for high-performance gaming PCs and workstations that generate significant heat from high-end components. It provides solid cooling performance to keep your system running well even under demanding applications. The sealing is achieved with high-quality EPDM O-rings, ensuring a durable and reliable seal.
Easy Installation and Strong Flexibility
Mount the EK-Quantum Kinetic3 FLT D5 PWM D-RGB on 140-mm fan mounts, making it a perfect fit for your gaming PC. No additional drilling is required, saving you time and effort. With eight G1/4-inch fittings, it offers versatile inlets and outlets and can be flexibly integrated into your system.
Enhance Your System with Light and Colours
Achieve a customised look with a variety of visual effects. The addressable, integrated D-RGB lighting beautifully showcases your PC. It connects via a 3-pin 5V Digital-RGB header. Your creativity has no limits.
- Dimensions: 148 x 278.5 x 86 mm (W x H x D)
- Material: Acrylic, EPDM rubber, anodised aluminium, stainless steel, PPS-GF40, aluminium oxide
- Colour: Transparent, Black (anodised aluminium cover)
- Volume: 445 ml
- Fittings: 8x G1/4-inch threads
- D-RGB Connection: 3-pin digital 5V LED header (+5V / Digital / Blocked / Ground)
- Number of LEDs: 32
- Pump: Integrated D5 PWM pump
Rated Voltage: 12 V DC
Power Consumption: 20 W
Max Head Pressure: 5.2 m
Max Flow Rate: 1.000 l/h
Max System Temperature: 60°C
Power Connection: SATA power and 4-pin PWM fan connector - Contents:
1x EK-Quantum Kinetic3 FLT D5 PWM D-RGB
L-shaped steel bracket with mounting screws
Mounting mechanism with all necessary screws
|
Colour
|
|
|
Primary Colour
|
Transparent
|
|
Dimensions
|
|
|
Length / Depth
|
86 mm
|
|
Width
|
148 mm
|
|
Height
|
278.5 mm
|
|
Volume
|
445 ml
|
|
Pump Specifications
|
|
|
Max. Pressure Head
|
5.2 m
|
|
Max. Water Flow
|
1000 l/h
|
|
Type
|
|
|
Pump type
|
D5
|
|
Power Specifications
|
|
|
Power Consumption
|
20 W
|
|
Rated voltage
|
12 V
|
|
Water Cooling
|
|
|
Water cooling component
|
Pump + Reservoir
|
|
Water cooling connectors
|
8x G1/4"
|
|
Internal Ports
|
|
|
Pump connectors
|
4 Pin (PWM control), SATA (power)
|
|
RGB / LED connectors
|
1x Digital RGB (3-Pin 5VDG)
|
|
Thermal Specifications
|
|
|
Max. System Temperature
|
60 °C
|
|
Materials
|
|
|
Materials
|
Acrylic glass, Aluminium oxide, Anodised aluminium, PPS-GF40, Rubber, Stainless steel
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
|
Lighting Colour
|
RGB
|
